BETENBENDER 6' x 120 Ton Hydraulic Press Brake Model 6-120

BETENBENDER 6' x 120 Ton Hydraulic Press Brake Model 6-120
$54,200 Manufacturer requires 10% steel surcharge to base price of ALL BETENBENDER machines.
Description
Please note: many products ship straight from manufacturer
*Due to unprecedented rise in steel costs, the manufacturer is requiring ALL distributors to add a 10% steel surcharge to the base price of Betenbender Machines
** FREE SHIPPING TO COMMERCIAL ADDRESS THAT CAN OFFLOAD**
***SHIPPING IS TO LOWER 48 STATES ONLY. OTHER AREAS PLEASE EMAIL
BETENBENDER 6' x 120 Ton Hydraulic Press Brake Model 6-120
- ACCURACY
- Every Betenbender machine is thoroughly inspected and tested.
- 1.Parallelism is maintained between bed and ram or at preset angle by using precision automatic leveling controls. Parallelism is maintained at +/-.002" in low speed.
- 2.The ram bottom reversal point is controlled by precise limit switches referenced off the bed. This isolates housing deflections, which can interfere with its accuracy.
- ENHANCED PRODUCTIVITY
- Return speed and rapid advance facilitates high cycle rates. Operator control is simplified by slow and press speed, thus work
- spoilage is avoided. Rapid advance with automatic change. The point of speed change is fully adjustable by electric limit switch.
- Micrometer type tilt adjustment is graduated in .001" increments permitting ram tilt adjustments up to 1/2" in either direction.
- ELECTRO MECHANICAL STROKE CONTROL is bed referenced.
- Bottom limit is manually set with a lead screw and displayed by an mechanical readout calibrated in .001" increments.
- VERSATILITY
- BETENBENDER'S press brakes have long full tonnage strokes, adjustable length and selectable speed combinations, adjustable height for short stroke, 2-speed standard and the optional 3- speed for adjustable low speed to prevent whip
- ELECRICAL EQUIPMENT
- Meets requirements of NFPA no.79, JIC and construction requirements of the latest ANSI B-11.3 Standards. Includes drip-proof, continuous duty 45 degree Celsius ambient hydraulic pump motor wired for 230 or 460 volt, 3 phase 60 hertz.
- DEPENDABILITY
- Self-lubricating replaceable non-metallic ways prevent galling and provide long service life. Cylinders are high-strength, all steel. To minimize wear and provide a superior oil seal, inside cylinder surfaces are honed to a mirror finish.
- Compact, precision machined aluminum manifold incorporates off-the shelf components, minimizes piping and consolidates "O" ring mounted valves.
- Quiet, vane type, constant volume pumps. In keeping with good hydraulic design practice, these energy efficient pumps are located outside the reservoir.
- Filtration of contaminants as small as 10 microns is accomplished with intake and discharge filters. A built-in magnetic trap and air breather filter provides added protection against contaminants. Reservoir of large capacity facilitates effective heat dissipation. A fluid level gauge is provided.
- CONTROL
- Main Control Cabinet - NEMA 12 enclosures mounted in the right housing containing: magnetic non-reversing motor starter and 120 volt circuit.
- Main motor START button and STOP button are illuminated.
- RAM UP and RAM DOWN buttons.
- RUN/JOG Switch.
- Fusible disconnect.
- MAINTENANCE
- Clevis mounted cylinders eliminate cylinder binding by reducing the possibility of oil leaks from cylinder binding.
- (Pins & bushings do not rotate under load, this reduces excessive wear)
- MADE IN USA
STANDARD EQUIPMENT:
- Clamp Type Back-gauge-Manual Adjustable X,Y,Z
- NEMA Electrics
- All Hydraulic Fluid Included
- American Made Motor
- Three Speed (95T and Larger)
- Hour Meter
- Lifetime Telephone Support @ No Charge
- Bottom Time Delay
- Three Position Foot Pedal
- Depth Stop w/Digital Readout
- All Steel Construction
- Disconnect Switch
- Two-Speed Ram
- All Components Available from Local Suppliers
OPTIONAL ITEMS: CALL FOR PRICE
- *Manual Front Reading Backgauge (24") w/Mechanical Readout
- Power Front Reading Backgauge w/5 Station NC "Go To" Controller on Pendant
- Power Ram Adjustment w/5 Station NC "Go To" Controller on Pendant
- Extra Length on Backgauge
- Micrometer Precision Gauge Unit (2 Required)
- CNC Ram Stop
- CNC Backgauge
- *24" Support Arms "Slide" Type
- Extend Support Arms (each)
- Disappearing Stops
- *Work Light
- *Variable Tonnage Control
- *One Shot Lubrication
- Automatic Lubrication
- Oil Cooler
- *Light Curtain w/Full Fence
- *Operator Station Palm Control
- Additional Foot Pedal w/Key Lock
- Palm Buttons/Foot Control System (Hand buttons to preset height, stop and hold, foot to continue to shut height.)
- Dove Tails or T‑Slots
- Ram Machining
- Bed Machining Angle Brackets
- Angle Brackets (Plates) for Top (4"x4") 18" Shorter than Bed
- Angle Brackets (Plates) for Bottom (4"x4") 18" Shorter than Bed
- Increase Throat Gap or Increase Open Height
- Increase Stroke Length
- Keylock Switch
- Die Rollover Bars (Recommended for 4/Way Dies)
- Air Lift (Recommended for 4/Way Dies)
- Dual Calibration
- 208V
- Crating Charge (Not An Export Crate) Still Requires Tarping
- Special Paint Colors
- Bolt/Shim Kit for Leveling
- Ram Stop Control (1/4" Above Die)
- Rigging, Lagging, Leveling & Electrical Hook Up is Customers Responsibility
- NOTE: DIE RISERS NOT FURNISHED
- ASK ABOUT OPTIONS NOT LISTED.
- ALL PRICES SUBJECT TO CHANGE WITHOUT NOTICE.
- *RECOMMENDED OPTIONS
Specifications
Manufacturer | Betenbender |
Model | 6-120 |
Condition | New |
Stock Number | 6-120 |
Maximum Tonnage | 120 Tons |
Maximum Bending Length | 72" |
Maximum Stroke Length | 8" |
Closed Height | 6" |
Open Height | 14" |
Throat Depth | 8" |
Distance Between Housings | 54-1/2" |
Ram Repeatability | +/- .002" |
Hydraulic Pressure | 2,500 lbs. |
Hydraulic Oil Capacity | 65 gallons |
Machine Weight | 17,000 lbs. |
Machine Dimensions: Overall Height | 103" |
Machine Dimensions: Overall Length | 100" |
Machine Dimensions: Overall Width | 56.5" |
Motor Horsepower | 20 |
