GMC Heavy Duty Hydraulic Box & Pan Brake HBB-1214

GMC Heavy Duty Hydraulic Box & Pan Brake HBB-1214

$34,850 FREE SHIPPING!

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer GMC 12' x 14 ga. Heavy Duty Hydraulic Box & Pan Brake HBB-1214

  • Taiwan Machines
  • ISO 9001 certified
  • Hydraulic adjustment for opening
  • Hydraulic power clamping for workpiece
  • 26” manual back gauge with handwheel
  • 1” manual beam adjustment ( front and back )
  • Min. reverse bend is ¾” (20mm)
  • Heavy welded all steel construction for maximum rigidity
  • Hydraulic logic system centrally located and quiet
  • A wide guidebody ensures strong, stable, smooth & accurate movement
  • Total pieces fingers assortment: HBB-1214: 3”/6pcs, 4”/4pcs, 5”/10pcs, 6”/10pcs
  • Central control panels on each side for convenient operation
  • Jog and auto operation modes
  • Overload protection and disconnect switch
  • One year warranty for parts


STANDARD EQUIPMENT:

  • Assorted fingers
  • 26” manual back gauge with one side handwheel operation
  • Angle set up dial
  • Hydraulic clamping system
  • Foot pedal control for hydraulic clamping & auto mode

OPTIONAL ITEMS - CALL FOR PRICE:

  • Optional Full Length Straight Finger
  • Safety fence for enclosure of the front side of the machine


Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts

Specifications

ManufacturerGMC Machine Tools
ModelHBB-1214
ConditionNew
Stock NumberHBB-1214
Max. bending length12'
Capacity mild steel14 Ga.
Capacity stainless steel16 Ga.
Bend angle135°
Max box depth6"
Large beam opening3"
Oil tank gal.50
Main motor10 HP, 220V/440V, 3PH
Overall dimensions180" x 46" x 69"
Mach weight8,950 lbs.
