GMC Hydraulic Box & Pan Brake HBB-0410

GMC Hydraulic Box & Pan Brake HBB-0410

$18,850 FREE SHIPPING!

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer GMC 4' x 10 ga. Hydraulic Box & Pan Brake HBB-0410

  • Taiwan Machines
  • ISO 9001 certified
  • Hydraulic adjustment for opening
  • Hydraulic power clamping for workpiece
  • 24” Manual Rear-operated backgauge
  • 1 manual beam adjustment ( front and back )
  • Min. reverse bend is 3/4 (20mm)
  • Heavy welded all steel construction for maximum rigidity
  • Hydraulic logic system centrally located and quiet
  • A wide guidebody ensures strong, stable, smooth & accurate movement
  • Total pieces fingers assortment:
  • HBB-0410 & 0412: 3/ 3pcs, 4/2pcs, 5/5pcs and 6/1pc
  • Central control panels on each side for convenient operation
  • Jog and auto operation modes
  • Overload protection and disconnect switch


STANDARD ITEMS:

  • Assorted fingers
  • 24” Manual Rear-operated backgauge
  • Angle set up dial
  • Hydraulic clamping system
  • Foot pedal control for hydraulic clamping & auto mode

OPTIONAL ITEMS - CALL FOR PRICE:

  • Optional Full Length Straight Finger
  • Safety fence for enclosure of the front side of the machine

Specifications

ManufacturerGMC Machine Tools
ModelHBB-0410
ConditionNew
Stock NumberHBB-0410
Max. bending length4'
Capacity mild steel10 Ga.
Capacity stainless steel12 Ga.
Bend angle135
Max box depth6"
Large beam opening3"
Oil tank gal.10
Main motor3 HP, 220V, 3-phase
Overall dimensions88" x 51" x 67"
Mach weight4,150 lbs
