U.S. INDUSTRIAL Hydraulic Press Brake with Front Operated Power Backgauge and Power Ram Adjust USHB155-13HM

U.S. INDUSTRIAL Hydraulic Press Brake with Front Operated Power Backgauge and Power Ram Adjust USHB155-13HM

Contact us for price

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer

U.S. INDUSTRIAL 13' x 155 Ton Hydraulic Press Brake with Front Operated Power Backgauge and Power Ram Adjust USHB155-13HM

  • Power Front Operated Back Gauge, motorized with fine adjustment handwheel
  • Power Ram Depth Control, motorized with fine adjustment handwheel
  • Digital Displays for backgauge position and ram position
  • All Steel Construction
  • Sick 4000 Light Curtain
  • Ram accepts standard American Tang tooling, 1/2” x 5/8”
  • Space between Ram Tool Clamps allows for deep box bending
  • Bed has slot for standard American Tang tooling
  • Bed also has capture clamps for tooling without tang
  • Free Gooseneck Punch and multi-opening Die for up to 90° forming in 10 gauge mild steel (Special Note: The Gooseneck Punch and multi-opening Die included are general purpose tools to be used for training only. Precision tooling should be purchased to meet your specific needs. The punch is segmented and it is up to the customer to calibrate these if they want to use them for a particular purpose. ­There is NO warranty on these items.)


EQUIPPED WITH:

  • Sick model 4000 light curtain system


OPTIONAL ITEMS:

  • Fiessler Akas II Laser Guarding
  • Pilz PSENvip LED Safety Guarding System
  • Training in our Memphis, TN Facility
  • Training at customer site, less than 300 miles from Memphis
  • Training at customer site, more than 300 miles from Memphis
  • Training outside continental USA



Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts

Specifications

ManufacturerUS Industrial
ModelUSHB155-13HM
ConditionNew
Stock NumberUSHB155-13HM
Working pressure155 Tons
Length of working table157.4"
Distance between housings124"
Throat depth12.5"
Stroke adjustment of ram2.75"
Ram travel5.9"
Open height16.3"
Rapid Ram Travel Speed2.4" / sec
Rapid Ram Retreat Speed2.0" / sec
Backgauge Travel24"
Pressing SpeedDependent on Tool Load
Hydraulic oil capacity97 gal.
Motor15 HP
Dimensions179" x 64" x 101"
Weight (approx.)23,148 lbs.
