GMC Heavy Duty Precision Gap Bed Lathe GML-2680

GMC Heavy Duty Precision Gap Bed Lathe GML-2680

$23,850

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer

GMC 26" x 80" Heavy Duty Precision Gap Bed Lathe GML-2680

  • ISO 9001 certified
  • Large spindle bore 4-1/8”
  • Heavy Duty spindle D1-8
  • Heavy Duty guideway width 16”
  • Heavy Duty main motor 15HP
  • Automatic kick-out longitudinal carriage stop system
  • 16 spindle speeds from 25-1,600 rpm, 16 speeds
  • 54 kinds of inch threads, and 54 kinds of metric threads
  • Threading and feeding rate change without changing gears
  • Spindle is balanced, hardened and precision ground
  • Spindle is supported at 3-point by high precision bearings
  • All gears and shafts are hardened and precision ground
  • Guideways induction hardened and precision ground
  • Automatic lubrication system in headstock and feed box
  • One year industrial warranty for parts

STANDARD ACCESSORIES:

  • Free Taper turning attachment, installed
  • Free SINO DRO, installed
  • Chuck guard with safety shut off
  • Automatic kick-out longitudinal carriage stop system
  • 12” 3-jaw chuck with top reversible jaws, direct mount
  • 16” 4-jaw chuck, direct mount
  • 18” Face plate
  • 7-1/2” large steady rest with roller jaws
  • 15” large steady rest with roller jaws
  • 3” follow rest
  • Removeable gap
  • 4-way tools post
  • Foot brake
  • Halogen Work light and coolant system
  • Full length splash guard
  • Dead centers
  • Thread chasing dial
  • Tool box and leveling pads


OPTIONAL ITEMS:

PART#900-0051-500: ALORIS type QC tool post set, 6 pcs: $1,850.00

PART#900-0050-05: Live Center: $195.00



Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts

Specifications

ManufacturerGMC Machine Tools
ModelGML-2680
ConditionNew
Stock NumberGML-2680
Max. swing over bed26"
Max. length of workpiece80"
Max. swing over cross slide17-1/4"
Max. Swing in gap35-3/8"
Width of Bed16"
Effective length in gap to spindle16"
Effective length in gap to chuck jaws4-1/2"
Spindle bore4-1/8", D1-8
Taper of spindle centerM.T. #5
Spindle speeds25-1,600 rpm / 16 steps
Longitudinal feeds0.0016-0.055 IPR, 25 kinds
Cross feeds0.0008-0.027 IPR, 25 kinds
Inch threads80-7/16 TPI, 54 kinds
Metric threads0.45-120 mm , 54 kinds
Module threads0.25-60mm, 46 kinds
Diametral pitch threads7/8-160 DP , 42 kinds
Max. travel of top slide9"
Max. travel of cross slide14-1/2"
Spindle length w/o chuck20-1/2"
Leadscrew length X TPI1-1/4” x 4 TPI
Diameter of tailstock quill3-1/2"
Max. travel of tailstock quill9-1/4"
Taper of quill centerM.T. # 5
Main motor15 HP, 220V or 440V, 3phase
Rapid traverse motor1HP, 220V or 440V, 3 phase
Coolant pump motor1/8 HP, 220V or 440V, 3 phase
Net Weight, approx.8,950 lbs
Overall Dimensions147" x 46" x 72"
