TENNSMITH Box and Pan Hand Brake F6-72-12

TENNSMITH Box and Pan Hand Brake F6-72-12

$7,040 RESTOCK DATE LATE DEC 2020

orCall 386-304-3720

Description

  • MADE IN USA
  • TENNSMITH'S F6 Series box and pan brakes were designed to provide heavy-duty forming capability, along with the flexibility of removable 6-inch box depth fingers. Ample clamping and easy-to-use nose bar adjustments allow for quick setting bend radius. Welded steel plate construction and heavy truss rods and braces provide strength and rigidity.
  • Other adjustment features include:
  • Leveling screws and lock nuts on the pedestals
  • Jack screws and tensioner bolts on the apron
  • Truss rods on the apron, base and upper beam
  • Fully adjustable counter balances to facilitate the bending process
  • Removable apron angle and insert permit 1/4 inch reverse bends in lighter material.


OPTIONAL ITEMS:

  • 85270: Extension Fingers (pair) for F6 Models: $395
  • Right and left extension fingers form inside corners with a return flange across the top on boxes, cabinets, etc.
  • 85275: Open End Fingers (pair) for F6 Models: $530
  • Provides triangular, square, tapered and rectangular tube forming abilities
  • 85280: F6 Radius Fingers (Please Specify Radii) - per inch: $30


Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 3 YEAR – Limited

Specifications

ManufacturerTennsmith
ModelF6-72-12
ConditionNew
Stock NumberF6-72-12
Capacity - Mild Steel12 ga
Capacity - Stainless Steel16 ga
Bending Length72"
Maximum Lift of Beam2-1/4"
Front to Rear Beam Adjustment1/2"
Maximum Depth of Box6"
Minimum Reverse Bend1/4"
Minimum Flange in Capacity Material1"
Finger Widths3, 4 and 5 in.
Dimensions (LxWxH) Counterweights in Place110" x 53" x 60"
Shipping Weight2,825 lbs.
