VICTOR Precision Heavy Duty Lathe 20120S

VICTOR Precision Heavy Duty Lathe 20120S

Contact us for price

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer VICTOR 20 X 120 inch Precision Heavy Duty Lathe 20120S

  • Extra large rigid compound rest and Meehanite casting bed provide excellent stability and consistency during machining. Large 3-1/8" spindle bore and 10 HP main motor are sufficient for high demanding jobs.
  • Oversized rigid compound rest for heavy cutting
  • Hardened and precision ground gears and bedways
  • Hardened and ground spindle nose
  • Full Meehanite casting bed
  • Headstock transmission gears driven by spline shafts
  • Spindle is supported at 3 points by precision bearings
  • Safety overload device
  • Inch/metric threading without changing gears
  • 10 HP main motor delivers full power at all 12 speeds
  • Dual speed tailstock quill (ratio 1:1 and 1:5) provides easy drilling operation
  • 2-way longitudinal (z-axis) power rapid traverse on 20120S and 20160S


STANDARD ACCESSORIES:

  • Removable gap
  • Tailstock with duo speed quill
  • Coolant system
  • Chuck cover with limit switch
  • D.P. / module thread change gears
  • Threading dial indicator
  • Center sleeve
  • Dead center M.T. #5
  • 2-way longitudinal z-axis power rapid traverse (20120S and 20160S only)
  • Leveling screws and pads
  • Manual and parts list


OPTIONAL ITEMS:

  • 10" 3-jaw chuck
  • 16" 4-jaw chuck
  • Steady rest with rollers
  • Follow rest
  • 4-way tool post
  • Halogen work light
  • Full length splash guard for 2040S, 2060S and 2080S only
  • On-carriage splash guard for 20120S and 20160S only


Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts

Specifications

ManufacturerVictor
Model20120S
ConditionNew
Stock Number20120S
Swing over bed20"
Swing over cross slide:13"
Swing over gap:26-3/8"
Bed width:15-3/4"
Distance between centers:120"
Spindle bore taper:M.T. #7
Taper of center in sleeve:M.T. #5
Spindle nose:D1-8
Number of spindle speeds:12 Steps
Range of spindle speeds (rpm):20 ~ 1,550 rpm
Speed selections:20, 30, 45, 60, 100, 150, 210, 350, 490, 680, 1100, 1550
Range of cross feeds:0.0007” ~ 0.01935”/rev.
Inch threads:2 ~ 112 TPI x 60 kinds
Metric threads:0.2 ~ 14 mm x 60 kinds
Compound slide travel:10”
Tailstock quill travel:6-5/16”
Main motor 10 HP, 3 Phase
Coolant pump:1/8 HP
Shipping dimensions (LxWxH) 185” x 44” x 65”
Gross weight: lbs.7,230
