ROPER WHITNEY AutoBrake AB1214

ROPER WHITNEY AutoBrake AB1214
Contact us for price
Description
Please note: many products ship straight from manufacturer ROPER WHITNEY AutoBrake AB1214 The Autobrake 1214 provides accuracy and repeatability when forming up to 12ft long 14 gauge or lighter materials. This sheet metal brake is a high speed solution to make multiple bends while maintaining a high quality level in the end product. Both backgauge options provide accurate part location through the use of servo drives and are expandable with optional backgauge extensions. The rigid design includes crowning adjustments to ensure accurate bending regardless of raw material stresses. ITEM: 12' x 14 ga. AutoBrake MANUFACTURER: ROPER WHITNEY MODEL: AB1214
Specifications
Manufacturer | Roper Whitney |
Model | AB1214 |
Condition | New |
Stock Number | AB1214 |
Maximum bending capacity, mild steel* | 14 ga |
Maximum bending capacity, stainless** | 16 ga |
Maximum bending length | 147.5" |
Drive motor 230/460v, 3 phase, 60 hz | 3 HP |
Back gauge motor 230/460v, 3 phase, 60 hz (if equipped) | 1/4 HP |
Floor space, gauges in position | 169" x 78" x 60" |
Dimensions | 181" x 89" x 68" |
Shipping weight | 11,000 lbs. |
