BEVELER USA B5 Beveler 110V, 1PH

BEVELER USA B5 Beveler 110V, 1PH

$999

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer BEVELER USA B5 Beveler 110V, 1PH Beveler B5 (max. width of bevel 0,2" / 5 mm) For the deburring of outer and inner outlines, bevelling, milling of radius and bore holes as from Ø 0,8" / 20 mm. Especially developed to produce clean visible edges and to prepare welds. Tool-less adjustment of bevel height. Handy and powerful. For construction steels, stainless steels, aluminium and other materials. Multiple indexable insert holder 45° (optional 60°, 30°). Also for radius R = 0,1" / 2.5 (only with indexable inserts R2,5mm ( 0,1"), catalogue no. 25205) High performance STANDARD EQUIPMENT: B 5 – Deburring and Bevelling Device 1 pc. milling tool 45° with indexable inserts 1 tool set Transport case 1 operation manual ITEM: Beveler 110V, 1PH MANUFACTURER: BEVELER USA MODEL: B5 PART# 25211 PART # ITEM 25213 30° SPARE INSERT HOLDER 25202 45°SPARE INSERT HOLDER radius R=2,5 25203 60° SPARE INSERT HOLDER 25209 INSERTS (1set=10pcs) 25205 RADIUS INSERT 2,5mm1 pc 25210 SCREW NMF0107 MAG BRUSH MAXX LARGE

Specifications

ManufacturerBeveler USA
ModelB5
ConditionNew
Stock NumberB5
Bevel angle:45° (optional 30°, 60°)
Bevel width 45°:Steel 0- 0,2") / 0 – 5 mm - 28 015 PSI / 400 N/mm2 infinitely adjustable Aluminium 0 – 5 mm ( 0-0,10") 250 N/mm2 infinitely adjustable
Bevel width 60°:Steel 0- 0,16" / 0 – 4 mm - 58 015 PSI / 400 N/mm2 infinitely adjustable Aluminium 0 – 4 mm( 0-0,16") 250 N/mm2 infinitely adjustable
Radius:R = 0,1" / 2,5mm
Motor voltage:110V/ 50-60Hz
Power:1300 W
Speed:4200 - 11 000 RPM with soft start with thermal and overload protection
Feed:manual
Dimensions20,09" x 16,94" x 7,88"
Weight:8,8 lbs / 4kg
Gross Weight16,54 lbs
