BEVELER USA UZ18 HARDWORKER Double Sided High Speed Beveler

BEVELER USA UZ18 HARDWORKER Double Sided High Speed Beveler


orCall 386-304-3720


Please note: many products ship straight from manufacturer BEVELER USA UZ18 HARDWORKER Double Sided High Speed Beveler Double Sided High Speed Beveler UZ 18 HardWorker, variable angle adjustment (maximum bevel width 18 mm/0,70". Automatic feed) The UZ 18 Hardworker machine is one of the most powerful DOUBLE SIDED PLATE BEVELER with the automatic feed in the market. It is suitable not only for workshops, but also for assembly operations. It has a continuous working angle adjustment system. Thanks to the special design of the drive system, the UZ 18 Hardworker is also suitable for tougher materials. During development, the emphasis was on high-quality processing of each part. Machine frame is made of steel, aluminum alloy worm gearbox, aluminium alloy cabinet. The machine is equipped with the automatic feed. Working with UZ 18 Hardworker is therefore very comfortable. For steel (strength up to 700 MPa), brass, copper and aluminium. For bevelling material with minimum dimensions - width 70 mm/2,76", length 150 mm/5,91", thickness 6 mm/0,24". Thickness of bevelled material 6 - 40 mm/0,23"-1,58". The bevel angle is easily adjustable from 15° to 50° - smoothly, without the need to replace any part. The equipment is capable of performing double-sided bevelling (X, K) without the need for material handling. Easy connecting to the 3D Manipulator for easier operation and handling. The machine is equipped with an automatic feed. The possibility of stationary and mobile use. The machine works on large workpieces without support. Smaller parts of the material are inserted directly into the machine. An advantageous price when purchasing UZ 18 Hardworker together with the 3D Manipulator. Included in price: Bevelling system UZ 18 Hardworker Tools for operators Instruction manual ITEM: Double Sided High Speed Beveler MANUFACTURER: BEVELER USA MODEL: UZ18 HARDWORKER PART# 1981, 1982, 1984, 1985 PART # ITEM 1930X 3D MANIPULATOR – allows to rotate the machine by 180° to create a two-sided bevel and facilitates the machine transport across the workplace. 2136 ECO cutting tool - Premium cutter - coated TiN - suitable for conventional steel 2137 ECO cutting tool 2134 ECO cutting tool - Set of 3 2142 PVD Cutting Tool 1936 PVD Cutting Tool - Set of 3 NMF0107 MAG BRUSH MAXX LARGE - magnetic sweeper equipped with wheels for collecting all magnetic materials – working width 450 mm / 17.71 in


ManufacturerBeveler USA
Max. bevel width:18 mm/0,70" (600 MPa)
Continuously adjustable angle:15° - 50°
Thickness of bevel. material:6 - 40 mm/0,24"-1,58"
Engine:750W / 380V
Feed:1,9 m/min.
Machine weight:242,55 lbs./110 kg
Gross Weight286.6 lbs.
Dimensions:27.95" x 20.47" x 39.76"
1981UZ18 HARDWORKER480V, 50Hz,3phase
1982UZ18 HARDWORKER220V, 60Hz,3phase
