NATIONAL Mechanical Shear NM1014

NATIONAL Mechanical Shear NM1014


orCall 386-304-3720


Please note: many products ship straight from manufacturer NATIONAL 10' (121") x 14 ga Mechanical Shear NM1014 These powerful Mechanical Shears are all USA made. They offer rugged welded construction, inch-bed scales, accurate table side gauges, hold-down finger guard with non-marring urethane, positive spring actuation and high carbon, high chrome long-life tool steel blades. The upper and lower blades are (4) four cutting blades and are interchangeable. Non-metallic gibs are maintenance free with self-lubricating bearings, continuous-cycle, single cycle and jog for different needs. Our shears also offer a fully guarded safety foot switch, quiet operation and low power consumption Standard high carbon high chromium blades All Steel Construction LIFETIME WARRANTY AGAINST BREAKAGE ON CUTTERHEAD, TABLE HOLDDOWN AND SIDE PANELS LIFETIME WARRANTY AGAINST BREAKAGE ON ALL STEEL MACHINES MADE IN USA

STANDARD EQUIPMENT: Front Support Arms Manual Rear Operated Sliding backgauge Worklight OPTIONAL ITEMS - CALL FOR PRICE: 60” Squaring arm

Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.



Stock NumberNM1014
Stainless Steel16 Gauge / 1.6 mm
Strokes Per MinuteApprox. 40
Cutting Length121"/3073 mm
Motor7.5 hp 208 v, 240 v, 460 v, 3 phase
Floor Space w/ Gauges141" x 32" x 53" (3581x2260x1346)
Floor Space w/o Gauges141" x 32" x 53" (3581x2260x1346)
Shipping Weight6,100 lbs (2767 kg)
