DOALL DC-800NC Production Bandsaw

DOALL DC-800NC Production Bandsaw

Contact us for price

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer DOALL 31.5" Production Bandsaw DC-800NC

  • Machine Capacity: w 39.5" x h 31.5" (1000mm x 800mm)
  • Production Level: High
  • Standard Features: Touch Screen Control, Nesting Fixtures and Retractable Shuttle Type Index Vise
  • The DC-800NC Continental Series™ high production horizontal band saw by DoALL is designed for cutting a wide range of materials in a fully-automated capacity.
  • If you are a primary metal supplier, foundry or cutting large parts for heavy-duty applications, the DC-800NC will provide you with both robust build quality and improved production.
  • The DC-800NC comes with digital touch screen controls, which operate the fully hydraulic accessories.
  • Touch Screen Control: Easy operator input. 20 Job storage with batching capabilities. Control is multi-lingual for today's workforce. Will display error message when incorrect entry is made. Easy switching between imperial or metric units.
  • High-Efficiency Transmission: High-efficiency worm gear box built to decrease wear and transmit full torque to the saw blade. Double wide “V” belt to avoid slipping, transmitting full motor power to the transmission.
  • Hydraulic Chip Conveyor: Adjustable speed auger style conveyor allows for coolant drain from chips before extraction.
  • Coolant Thru Carbide Faced Saw Guide Inserts: Supplies coolant to the blade evenly before and after the cut creating straighter cuts and allowing longer blade life due to coolant being supplied at the tooth tip.
  • Efficiently Designed Hydraulic System: Engineered low-pressure system allows for a smoother and quieter operation which aids in longer component life and easy accessibility for maintenance.
  • Band Wheels: 30 Degree lay-back head design minimizes band twist which causes band fatigue and also allows a smaller foot print. Flange cast steel wheels insure band tracking to prevent tooth set lost.
  • Underslung Indexer System: Reduces friction when indexing heavier or rough surface material by the use of rollers allowing for smoother material movements.
  • Movable Saw Guide Arm: An electrical driven movable guide arm with a hydraulic lock system aids the operator in the placement of the arm close to the cut minimizes blade deflection.
  • Hydraulic Blade Tension: Eliminates possible error of over/under-tightening the band for maximum cutting rates and band life.
  • Back-up Bearing/Inserts: Supports the back of the saw band allowing the creation of band preload which aids in reducing vibration while cutting and increasing blade life.
  • Retractable Shuttle Type Index Vise: Both jaws retract when vise is opened to accommodate the movement of crooked stock increasing accuracy and repeatability.
  • Magnetic Scale for Indexer: The scale which creates indexing accuracy is protected from dirt and oil build up insuring its long life.
  • Nesting Fixtures: Plug-n-play vertical hold-down clamp assemblies allow the operator to perform multiple-piece cutting to increase productivity.
  • Warranty: One-year parts and service subject to the terms and conditions. 10-year manufacturer’s warranty available (Cut Above Lifetime Warranty).


STANDARD EQUIPMENT:

  • Programmable Logic Controller for all machine functions
  • Feed rate/feed force saw head control
  • Infinite band speed controlled variable frequency drive
  • Hydraulic retractable shuttle vice material indexer on chrome rails
  • Rapid and creep speed index vice control
  • Full stroke vices with moveable outboard front vise
  • Variable vice pressure control
  • Vertical hydraulic cylinders with hold down fixtures
  • Hydraulic set, zero clearance, coolant through,
  • carbide faced saw guide inserts with lead in rollers
  • Adjustable power driven band cleaning brushes with coolant flush line attached
  • Halogen work light
  • Electric motor driven movable saw guide arm
  • Blade shock proof device
  • Flushing hose for machine wash down and auxiliary coolant nozzles
  • Hydraulic band tension
  • Hydraulic adjustable speed auger design chip conveyor
  • One shot column lubricator
  • Saw band break/stall motion detector shut off switch
  • Band door interlocks
  • Operation and parts manuals on USB stick
  • One 6.5 ft. (2M) idler input conveyor
  • Maintenance tool kit
  • Complimentary DoALL Cutting Fluids package
  • One (1) complimentary DoALL Bi Metal saw blade


OPTIONAL ITEMS:

  • 10 ft. idler conveyor
  • 5 ft. idler conveyor with filler plates
  • Out of square detection
  • Additional USB stick of manuals
  • Laser line
  • A Nationally Recognized Testing Laboratory (NRTL) is an independent third-part laboratory recognized by the United States Occupational Safety and Health Administration (OSHA) to test and certify products to applicable product safety standards.
  • DoALL Cut Above 10 Year Warranty Annual Investment


Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR – Parts

Specifications

ManufacturerDoALL
ModelDC-800NC
ConditionNew
Stock NumberDC-800NC
Cutting Capacity - Round31.5" (800mm)
Cutting Capacity - Rectangle (W x H)31-1/2 x 39-1/2" (800x1000mm)
Saw Blade - Width x Length2.625" x 347"
Band Drive - Motor HP15 HP
Band Drive - Band Speed52-275 fpm
Band Drive - Band TensionHydraulic
Hydraulic System - Motor HP3 HP
Hydraulic System - Reservoir Size34 Gallon
Coolant SystemFlood coolant
Coolant System - Motor HP1/4 HP
Coolant System - Reservoir Size63 Gallon
Indexer - Length per Stroke15.75"
Indexer - Maximum Index Strokes Length236"
Indexer - Remnant Length9" (non bundle)
Voltage Requirement230V-60Hz-3ph, Wye configuration
Total Amp Draw (FLA)61 Amps
Floor Space Dimensions W x L X H172" x 94" x 108"
Material Pass Height36"
