SHARP Radial Drill RD-2000

SHARP Radial Drill RD-2000
Contact us for price
Description
Please note: many products ship straight from manufacturer SHARP Radial Drill RD-2000 Sharp radial drills are excellent machines for tapping, drilling and boring large holes on cast iron or steel material. The traveling arm is made with hardened and ground slide ways for precise movement of head and spindle. The vertical column utilizes double tube design for rigidity. The spindle is equipped with depth setting. The Sharp heavy duty Radial Drilling Machines are designed for a wide range of machining operations to be used under the most demanding conditions. All major castings are made of closed grained full ribbed iron to give maximum stability under stress. The headstock gears are made of hardened and ground nickel-chrome alloy steel. The arm is mounted with ground slideways and operated by electric control. It has a safety device that will prevent the arm from dropping due to unforseen reasons. The rigidly ribbed casting base is provided with T-slots and drain channels. The spindle is designed for maximum speed, feed rate and depth. STANDARD EQUIPMENT: Box table Coolant system Work light Toolbox ITEM: 78" Radial Drill MANUFACTURER: SHARP MODEL: RD-2000 Tilting table
Specifications
Manufacturer | Sharp |
Model | RD-2000 |
Condition | New |
Stock Number | RD-2000 |
Diameter of column | 17" |
Dist. column to spindle | 16.93"-78.74" |
Travel of spindle head | 61.81" |
Dist. Spindle to base | 15.34"-72.83" |
Elevating height of arm | 43.31" |
Effective area of table | 40" x 32" x 20" |
Dimensions of base | 115" x 45" x 10" |
Taper hole in spindle | MT# 5 |
Stoke of spindle | 14.57" |
Spindle (rpm range x steps) | 40-1920 x 12 |
Spindle feed (ipr x steps) | 0.007"-0.96" x 6 |
Main motor (HP) | 7.5 HP |
Elevating motor (HP) | 3 HP |
Clamping Motor for Column & Gear Box | 1 HP |
Clamping Motor for arm (HP) | 1/2 HP |
Coolant Pump | 1/8 HP |
Machine height from floor, max | 136.61" |
Measurement (LxWxH) | 130" x 59" x 123.6" |
Approx shipping weight (lbs) | 15,620 |
Capacity Tapping Steel | 2" |
Capacity Tapping Cast Iron | 2-3/8" |
