JET J-A5816 Variable Speed Floor Model Drill Press 115/230V 1Ph, JT9-354550, JT9-354551
JET J-A5816 Variable Speed Floor Model Drill Press 115/230V 1Ph, JT9-354550, JT9-354551
$2,529
Description
Please note: many products ship straight from manufacturer JET J-A5816, 15 inch Variable Speed Floor Model Drill Press 115/230V 1Ph, JT9-354550, JT9-354551 These JET Drill Presses use a variable-speed motor with the stepped-pulley system, and come equipped with a continuously variable transmission. This enables use at a wide range of speeds, as well as the ability to change speed during operation. A scale-marked hand wheel that matches the desired machine speed is mounted to a reduction gearing system for precise operator control. This adjusts the gearing ratio between the motor's fixed pulley and the output shaft's variable pulley, changing the speed of the chuck. A tensioner pulley is implemented in the belt transmission to take up or release the slack in the belt as the speed changes. Full bearing support on quill for maximum spindle stiffness Handwheel speed adjustment of 400 to 5,000 RPM Large 2-1/4" quill for greater accuracy 3" column diameter for maximum head support 6" stroke for deep hole application Accurate depth stop for precise hole depths 1/2" drill chuck and arbor included Safety collar
OPTIONAL MODEL:
STOCK# JT9-354551: J-A5818 15" Variable Speed Floor Model Drill Press 230/460V $2,529.00
Specifications
| Manufacturer | Jet |
| Model | J-A5816 |
| Condition | New |
| Stock Number | JT9-354550 |
| Drills to Center of Circle (in.) | 15 |
| Drilling Capacity Cast Iron (in.) | 5/8 |
| Drilling Capacity Mild Steel (in.) | 1/2 |
| Column Diameter (in.) | 3 |
| Distance Column to Spindle (In.) | 7-1/2 |
| Spindle Travel (In.) | 6 |
| Spindle Distance to Base (In.) | 44-1/2 |
| Spindle Distance to Table (Max.) (In.) | 25-3/4 |
| Table Size (L x W) (In.) | 5 x 8 |
| Table Travel (In.) | 16-3/4 |
| T-Slots Number and Size (In.) | 2 and 1/2 |
| T-Slot Centers (In.) | 5-5/16 |
| Work Table Weight Capacity (Lbs.) | 90 |
| Spindle Taper (In. x TPI) | MT-2 |
| Range of Spindle Speeds (RPM) | 400 - 5000 |
| Base Dimensions (In.) (L x W x H / in.) | 20-7/16 x 14-3/16 x 3-1/8 |
| Base Slots Number & Size (in.) | 2 & 1/2 |
| Overall Dimensions (in.) | 30 x 20 x 71 |
| Weight (lb.) | 426 |
