ERCOLINA GIGA BENDER CNC Mandrel Bender GB100CNC6

ERCOLINA GIGA BENDER CNC Mandrel Bender GB100CNC6

Contact us for price

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer ERCOLINA GIGA BENDER CNC Mandrel Bender GB100CNC6 ITEM: 4-3/4" CNC Mandrel Bender MANUFACTURER: ERCOLINA MODEL: GIGA BENDER PART# GB100CNC6 Ercolina's GB100 CNC mandrel bender is ideal for bending tube, pipe, square and rectangular profiles to a center line radius as tight as 1.5 x diameter. Large radii tooling is available to 16" CLR. Interactive PLC touch screen offers easy access to auto and manual operating modes, system diagnostics and multiple language capability Programmable bend angles with independent material spring back setting for each bend Programmable auto mandrel positioning allows operator to optimize extraction for improved bend quality Programmable clamping, pressure die and boost movements with manual override USB for unlimited program memory storage and communication Precision encoders on each axis Touch screen displays absolute (ABS) or incremental (INC) positioning with inch or metric readout Programs in YBC or XYZ input value Programmable tail stock interference zone monitors position and eliminates workhead collision GB100 standard hydraulic ports accept Ercolina® patented (KST) clam shell clamp systems Hand-held remote bending control, certified class 3 safety and all electrical components UL, CSA and CE approved Standard programmable internal mandrel lubrication Super Bend-Tech SE for Ercolina® software included Accepts YBC and XYZ input values Y - Feeding Hydraulic B - Feeding Hydraulic C - Bending Hydraulic CNC

Specifications

ManufacturerErcolina
ModelGB100CNC6
ConditionNew
Stock NumberGB100CNC6
Stainless4-3/4" (.150 wall)
Square Tube4" x 4" (.156 wall)
Pipe Capacity (Max.) - A363" Sch. 40
Tube Capacity (Min.)1"
Bend Radius (Max. | Min.)16" | 1.5D
Material Length (Max.)13' (Optional 20' table)
Hydraulic Clamping(KST) Clam Shell
(C Axis) Rotation / Bend AngleCCW / 0° to 180°
(B Axis) Bend Plane RotationAuto positioning with digital display
(X2) Pressure Die Linear TravelProgrammable with digital readout
Program StorageUnlimited with USB
Hydraulic Reservoir40 gal.
Motor (horse power @ 480V)30
Dimensions (Height x Width x Length)298" x 51" x 55"
Weight7,200 lbs.
