TENNSMITH Air Shear MODEL 36A

TENNSMITH Air Shear MODEL 36A

$4,555

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer TENNSMITH Air Shear MODEL 36A ITEM: 37" x 16 ga Air Shear MANUFACTURER: TENNSMITH MODEL: 36A MADE IN USA TENNSMITH'S power shears combine all of the features of our foot shears with the advantage and convenience of air or hydraulic operation. TENNSMITH power shears are a productive addition to any shop. The air shears utilize heavy-duty, tie rod-type pneumatic cylinders, which provide up to 40 strokes per minute in capacity materials. A foot-operated air valve control, pressure regulator, air gauge, oiler/condenser cups and neoprene, padded holddown feet are standard features. We recommend a maximum air supply of 75 psi for operating these shears at rated capacity. Where air supply pressures exceed 75 psi, an in-line regulator is helpful to provide pressure control. The Model 52H cycle at 45 strokes a minute, thanks to its first class hydraulic system. The hydraulic unit is of a low maintenance design featuring a solenoid actuated valve, 3-HP electric motor, self-contained pump in tank with pressure gauge, check valve and industrial quality cylinders. The motor is protected by a magnetic starter. Other electrical safety features include a low voltage on/off switch; low voltage, shrouded, electric foot switch; step-down transformer with low voltage circuit fuse; fully enclosed electrical box; and insulated reinforced conduit for all wiring. Models 36A and 52A are ideal ways to enhance shearing productivity with minimal investment. STANDARD EQUIPMENT: High Carbon/High-Chromium (HCHC) Blades Back gauge Front extension arms with stop Bevel gauge Graduated side gauges Foot control Neoprene padded hold down feet OPTIONAL ITEMS: 81545: 36" HCHC Blades, per set: $590 4' Squaring Arm: $610

Specifications

ManufacturerTennsmith
Model36A
ConditionNew
Stock Number81040
OperationAir
Maximum shearing capacity, Mild Steel16 gauge/1.6mm
Maximum shearing capacity, Stainless Steel20 gauge/1.0mm
Maximum cutting length37" / 940mm
Back gauge range30" / 762mm
Front gauge range37" / 940mm
Floor space, gauges in position45" x 80"
Dimensions, Less gauges, LxWxH46-1/4" x 24" x 42"
Strokes per minute, full length40
Maximum Operating Pressure75 psi
Air Consumption per Stroke1.1 cu. ft.
Shipping Weight:800 lbs. / 363 kg
