GMC Machine Tools Heavy Duty Hydraulic Shear HS-0808E

GMC Machine Tools Heavy Duty Hydraulic Shear HS-0808E

$22,850

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer GMC Heavy Duty Hydraulic Shear HS-0808E ISO 9001 certified Taiwan machines 24” German SIKO Front Operated power back gauge w/ micro adjustment 0.004” , inch/mm digital display for HS-0425E, & HS-0625E & 36” for HS-0808E 36” NC go-to power back gauge with touch screen for HS-1025E & HS-0825E Quick Change Blade Gap Adjustment (BGA), with gap dials CE standard “OMERO” electric control system Meet OSHA safety standard code Shadow line for accurate straight cutting Adjustable cutting length and stroke Ball transfer plates on worktable for easy loading workpiece Well balanced and sturdy all steel machine frame German made Hydraulic logic system centrally located and quiet Hydraulic hold-downs with anti-mar neoprene Shear blades are high grade carbon/chrome alloy steel and hardened to 60 HRC, 2-edge indexable upper blade and 2-edge indexable bottom blade Full length viewable safety finger guard to protect operator from cutting hazard Removable safety foot pedal, automatic blade raise up on removal of foot from pedal Hydraulic, electrical overload protection Compact operator control panel All motors are overload protected & low voltage control system Jog or continuous auto cycle cutting operation modes One year industrial warranty for parts EQUIPPED WITH: 24” German SIKO Front Operated Power Back Gauge with micro adjustment , accuracy 0.004” inch/metric digital display 36” go to NC back gauge w/ touch screen is for model HS-0825E and HS-1025E 1 each 60” squaring arm with inlaid inch/metric dual scale Quick change blade gap adjustment (BGA) with dials Shadow line for accurate straight cutting Material support and drop back chuter Upper and bottom blade set with 2-edge on bottom & 2-edge on upper 2 each 24” front support arms Hydraulic hold-downs with anti-mar neoprene Full length viewable finger guard Removable safety foot pedal Tool box

OPTIONAL ITEMS: CALL FOR PRICE Safety fence for enclosure of the back side of the machine

Specifications

ManufacturerGMC Machine Tools
ModelHS-0808E
ConditionNew
Stock NumberHS-0808E
Cutting capacity: mild steel, stainless steel8 x 8ga, 8 x 11ga
Blade length8'
Strokes per minute10-15
Throat depth18"
Worktable height34-1/2"
Front support arm24"
Back gauge for E model36” power B.G
Blade rake angle2 degree
Oil tank cap.35 Gal.
Main motor10 HP, 220V, 3-phase
Power B.G. motor1 HP
Machine weight8,850 lbs
Machine dimensions157” x 89” x 65”
