DOALL Semi-Automatic Bandsaw DC-560SA

DOALL Semi-Automatic Bandsaw DC-560SA

Contact us for price

orCall 386-304-3720


Please note: many products ship straight from manufacturer DOALL Semi-Automatic Bandsaw DC-560SA ITEM: 22" Semi-Automatic Bandsaw MANUFACTURER: DoALL MODEL: DC-560SA The DC-560SA Semi-Automatic Continental Series of high production, horizontal band saws by DoALL are designed for cutting a wide range of metals on a production basis. While DoALL semi-automatic saws do not offer an auto-indexing, they do cut single pieces extremely efficiently. If you have operations that do not require indexing, high production or automatic cutting cycles, an affordable DoALL semi-automatic saws is the perfect choice. Once you have set your desired feed rate, blade speed and initial vise opening, a cut is complete, the band shuts off and the head returns to the upright open position and locks. Then the operator must manually reposition the material for another cut. Semi-automatic operation also increases blade life and cutting accuracy as the operator is not manually pressuring or overloading the saw blade during the cut. STANDARD EQUIPMENT: Programmable Logic Controller (PLC) control for all electric and hydraulic functions Multi-step full stroke vises with split front vise and variable vise pressure control Spring loaded, zero clearance, coolant through, carbide faced saw guide with lead-in rollers Power driven, coolant flushed, blade cleaning wire brush Flushing hose and auxiliary coolant nozzles Hydraulic blade tension Automatic chip conveyor Blade breakage/stall motion detector shut off switch Band door interlocks Work light One set of 6-foot (2-meter) roller stands Set up tools and tool box Complimentary DoALL Cutting Fluids package One DoALL bi-metal saw blade Instruction and parts manuals on CD or USB data stick Additional 10 foot (3m) conveyor Magnetic chip remover


Stock NumberDC-560SA
Rectangle: (W x H)22" x 31-1/2" (560x800mm)
Maximum Nesting Capacity at 90°18.9" x 11" (480x280 mm)
Minimum Nesting Capacity at 90°10.2" x 6.3" (260x160 mm)
Band Saw Blade (L x W x Gage)268" x 2" x 0.063" (6800x54x1.6 mm)
Band Speed52-279 FPM (16 – 85 m/min)
Band Drive10 hp (7.5 kW)
Hydraulic Pump3 hp (2.2 kW)
Hydraulic Tank Capacity31.7 gal (120 lit)
Coolant Motor1/4 hp (0.2 kW)
Coolant Tank Capacity37 gal (140 lit)
Material Pass Line Height33-1/2" (850 mm)
Dimensions (W x L x H)130" x 77" x 79" (3300x1950x2000mm)
Machine Weight8,378 lbs (3,800kg)
