BIRMINGHAM Vertical Metal Cutting Band Saw KV-100
BIRMINGHAM Vertical Metal Cutting Band Saw KV-100
Contact us for price
Description
Please note: many products ship straight from manufacturer BIRMINGHAM 40" Vertical Metal Cutting Band Saw KV-100
- Saw blade butt welder with integrated annealing unit
- Blade shear, grinder
- Brush for cleaning lower drive wheel
- Low voltage working lamp
- One set of required tools
- One instruction and parts manual
OPTIONAL ITEMS:
- Rip fence for straight, repeated cuttings easily removable for varied size
- Miter protractor for angular cutting
- Groove table
Specifications and design are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
Specifications
| Manufacturer | Birmingham |
| Model | KV-100 |
| Condition | New |
| Stock Number | KV-100 |
| Cutting Capacity - Blade to Column | 39-3/4" (1010mm) |
| Cutting Capacity - Max, work height | 11-1/2" (340mm) |
| Table Size | 23-1/2" x 19-1/2"; 17-3/4" x 19-1/2" |
| Table inclination (4 ways) | 15° |
| Saw Blade Length | 178-5/8" |
| Saw Blade Width | 3-16mm |
| Saw Blade Speeds | Low 20-85m/min (65-280 fpm) High 120-500m/min (400-1640 fpm) |
| Butt Welder Capacity | 2.4 KVA 3-16mm (1/8" - 5/8") |
| Drive Motor | 2 HP, 3-phase, 220V |
| Net Weight (approx.) | 1,168 lbs. |
| Gross Weight (approx.) | 1,367 lbs. |
| Measurement (LxWxH) | 69-7/16" x 29-13/16" x 84-5/16" |
