COLE-TUVE 3-Roll Variable Axis Plate Bending Rolls 3R UHS 10-350

COLE-TUVE 3-Roll Variable Axis Plate Bending Rolls 3R UHS 10-350

Contact us for price

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer 10' x 3/4" - 2" COLE-TUVE 3-Roll Variable Axis Plate Bending Rolls 3R UHS 10-350 High versatility on heavy plate bending operation Reduced overall dimensions and easiness of transportation for medium and big machines Having the two bottom rolls horizontally moving, means also a lower working height which requires a smaller foundation pit and less anchoring load (in the smallest models you don't need foundation) During production (pre-bending and bending phases), the plate keeps always its horizontal position The solid construction and the particular geometry of the 3R UHS enable to be used as a press bending machine The 3R UHS machine can fulfill the best pre-bending on every required diameter. The possibility to reduce centre-distance between lower rolls realizes a better pre-bending during bending of tubes with small diameter and thickness Another important feature of the 3R UHS machine is the operating system of the top forming roll. In fact, the top forming roll can be used as a traditional press allowing perfect re-rolling and calibration operations of the produced tubes In the same way it is also possible to obtain cones with heavy thicknesses by bending in several strokes the plate With some 3 and 4 rolls pyramidal machines it is necessary to tilt the top roll to allow the produced tube removal. On the 3R UHS machine this is no necessary and therefore it is much more easy to remove the tube Large working stroke allows to get best bending result OPTIONAL MODELS - CALL FOR PRICE 3R UHS-10-350: 10' x 3/4" 3R UHS-10-450: 10' x 1-1/2" 3R UHS-10-550: 10' x 2" ITEM: 10' x 3/4" - 2" 3-Roll Variable Axis Plate Bending Rolls MANUFACTURER: COLE-TUVE / SAHINLER MODEL: 3R UHS 10-350 / 3R UHS 10-450 / 3R UHS 10-550

Specifications

ManufacturerCole-Tuve
Model3R UHS 10-350
ConditionNew
Stock Number3R UHS 10-350
3R UHS-10-35010' x 3/4"
3R UHS-10-45010' x 1-1/2"
3R UHS-10-55010' x 2"
