BIRMINGHAM Hydraulic Plate Bending Roll R-0425H

BIRMINGHAM Hydraulic Plate Bending Roll R-0425H

$9,000

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer 4' x 2.5mm BIRMINGHAM Hydraulic Plate Bending Roll R-0425H Three rolls are driven by hydraulic power Pinch roll cylinders are adjusted simultaneously for added convenience All rolls are manufactured of high quality alloy steel and hardened to HRC 55°. Ruggedly constructed for precise and smooth operation as well as long service life. Top roll can be swivelled to facilitate removal of the finished workpiece Foot switch provides forward and backward motion control, and is protected by a housing Machine power shuts off automatically, when top roll swivels out from from the end frame. NOTE: Bigger Model R-0840H (4.0mm x 2540mm) and R-1020H (2.0mm x 3050mm) are available on request ITEM: 4' x 2.5mm Hydraulic Plate Bending Roll MANUFACTURER: BIRMINGHAM MODEL: R-0425H

Specifications

ManufacturerBirmingham
ModelR-0425H
ConditionNew
Stock NumberR-0425H
Mild Steel Capacity2.5mm x 1300mm
Roll Diameter95mm (3.74")
Hydraulic Powered Pinch adjustmentStandard
Motor1.5 HP
Roll Speed3.6 m/min
Shipping Crate Size85" x 34" x 53" (2150 x 850 x 1350mm)
Shipping Weight1,433 lbs.
