AKYAPAK 3-Roll Asymmetrical Plate Roll ASM-S 190-20/6.0

AKYAPAK 3-Roll Asymmetrical Plate Roll ASM-S 190-20/6.0
Contact us for price
Description
Please note: many products ship straight from manufacturer AKYAPAK 6.5' 3-Roll Asymmetrical Plate Roll ASM-S 190-20/6.0 ASM-S, stand out as a high quality asymmetrical plate roll machine with its user friendly features. ASM-S model is made of complete steel (ST-52) construction, strong and powerful. The top and lower rolls are driven by electric motor + gearbox and gear system. Induction hardened rolls Backroll with motor Cone bending device Body steel (St-52) construction Rolls are produced by special steel Machine designed in asymmetrical working principle Central rollers powered with electric motor + gearbox and gear system Upper roll is openable by side Separate control panel Suitable for CE, ISO 9001-2008
OPTIONAL ITEMS: Lower roll with motor Digital display Extended rolls Profile rolls
*Data based upon 35.000 PSI yield point.
*For cone bending, all bending values must be reduced %50.
*Pictures shown in this offer are just for demonstration, might be with or without optional equipments.
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR
Specifications
Manufacturer | AKYAPAK |
Model | ASM-S 190-20/6.0 |
Condition | New |
Stock Number | ASM-S 190-20/6.0 |
Working length | 6.5" |
Maximum thickness | Pre-bending – 0.250” Bending – 0.275” Yield Point: 35.000 PSI |
Number of rolls | 3 |
Motor Power | 5.4 HP |
Min. Bending (in - Ø) | 11.2" |
Top roll (in - Ø) | 7.5" |
Bending Speed | 16.4 ft/min |
Length x Width x Height | 150" x 52" x 53" |
Weight | 7,937 lbs. |
