ROPER WHITNEY Slip Roll NO. 392

ROPER WHITNEY Slip Roll NO. 392
$4,408
Description
Please note: many products ship straight from manufacturer ROPER WHITNEY Slip Roll NO. 392 The No. 392 manual roll has 2-1/2″ precision turned and ground high carbon steel rollers. There are four wiring grooves 1/4″, 9/32″, 5/16″ and 3/8″. All rolls are standard with fully enclosed gear housings and all three rolls are driven. The upper roll lifts for conventional removal of the work piece. The maximum sheet length is 48″ with a thickness capacity of 20-22 gauge mild steel. MADE IN USA ITEM: 4' (48") x 22 ga. Slip Roll MANUFACTURER: ROPER WHITNEY MODEL: NO. 392 PART# 167070392 PART # ITEM 239006009K NO. 392 Heavy Duty Welded Floor Mount Stand - 200 lbs.: $578
Specifications
Manufacturer | Roper Whitney |
Model | NO. 392 |
Condition | New |
Stock Number | NO. 392 |
Catalog No. | 167072392 |
Capacity - Mild Steel | 20-22 ga |
Max. Forming Length | 48" |
Roll Diameter | 2-1/2" |
Minimum Forming Radius | 1.25" |
Gearing Ratio | 2.4:1 |
Wiring Grooves | 1/4", 9/32", 5/16", 3/8" |
Dimensions | 77" x 18" x 17" |
Shipping Weight | 540 lbs. |
