MANFORD SP150VSL Super Precision Vertical Turret Milling Machine

MANFORD SP150VSL Super Precision Vertical Turret Milling Machine

$9,000

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer MANFORD 9" x 49" Super Precision Vertical Turret Milling Machine SP150VSL 9” X 49” Table, Hardened & Ground Table with Ground T-Slot 3HP Spindle Motor, variable speed R8 (NST#30) Spindle Material Scm415(SAE4115)Hardened & Ground. Bearing support to the motor shaft Unique rigid design on spindle auto-feed, spline design on the pinion & clutch support Turcite-B On X&Y Ways, Slide-ways and Gibs. Hardened & Ground X&Y Slide-ways. Electroless Nickel-Phosphorus Process On X&Y lead-screw with hardness 35 HRC. Lead-screw nut made from PBC2, phosphor bronze Highly Improved Vari-Speed Head. 1-1/4”(32mm) Diameter Lifting Screw. Leveling Screw & Plate On Base. Strict Requited Scraping with High Precise Accuracy. Tool box & Tools Rubber chip cover (front & rear ) Made in Taiwan 2 years parts warranty - Two-year warranty for all mechanical and one-year for electrical components ITEM: 9" x 49" Super Precision Vertical Turret Milling Machine MANUFACTURER: MANFORD MODEL: SP150VSL EVS Head, 3HP inverter motor with Driver 60-5000 rpm Align AL-500 Power feed for X Servo model 150 Power Feed X (M-0200-150) Servo model 150 Power Feed Y (M-3550-150) Align AL-500 Power feed for Y OR Z Servo power feed (Z axis) Model 200 (M-3580-200) Coolant system (1/8 HP,3PH,220V ) Coolant tray (Base) Riser block 4” /6”/8” Quartz work light 6” Angle-fixed milling vise with swivel base Clamping kit (54 pcs) R8 Right Angle Attachment complete set Newall DP700 mill package, 3 Axis Newall DP700 mill package, 2 Axis Acu-Rite VUE DRO, 2 axis Acu-Rite 200S DRO, 2 axis Acu-Rite 200S DRO, 3 axis with Quill scale Acu-Rite 200S DRO, 3 axis with knee scale Mitutoyo Quill kit MAXI TORQUE-RITE power drawbar (R8 ) Taiwanese Power Drawbar

Specifications

ManufacturerManford
ModelSP150VSL
ConditionNew
Stock NumberSP150VSL
Table9” x 49” (230 x 1245mm)
T-Slot No.x Size3” x 5/8” (3 x 15.875mm)
With power feed34”(863mm)
Cross travel12” (305mm)
Travel of knee16” (406mm)
Ram travel14” (356mm)
Quill travel5” (127mm)
Table to spindle nose (D)1-3/8” - 17-3/8” (34-440mm)
Over swivel on turret360°
Head Swivel ( R & L )90°
Head tilt ( UP & DOWN )45°
Spindle to column (F):6”-21” (153-544mm)
Spindle motor:3HP
Spindle taperR8 (or NST#30)
Quill feed0.0015” - 0.003” - 0.006”
Spindle Speed (r.p.m.):( 60Hz) 60-4500, ( 50Hz ) 50-3800
Overall height (A):84” (2140mm)
Overall depth (B):63-5/8” (1618mm)
Overall width (C):59” (1497mm)
Net Weight2,200 lbs. (950 Kgs)
