GMC Heavy Duty Gap Bed Lathe GML-1440HD

GMC Heavy Duty Gap Bed Lathe GML-1440HD


orCall 386-304-3720


Please note: many products ship straight from manufacturer GMC 14" x 40" Heavy Duty Gap Bed Lathe GML-1440HD ISO 9001 certified Large spindle bore 2-1/16” Heavy Duty spindle D1-6 One-piece solid cast iron machine base Heavy Duty guideway width 10-1/4” Heavy Duty main motor 6 HP 16 spindle speeds from 45-1,800 rpm, speeds: 45/ 75/ 90/ 130/ 160/ 195/ 210/ 260/ 350/ 390/ 600/ 690 / 790 / 910/ 1,200/ 1,800 rpm 45 kinds of inch threads, and 39 kinds of metric threads Threading and feeding rate change without changing gears Spindle is balanced, hardened and precision ground Spindle is supported at 3-point by high precision bearings All gears and shafts are hardened and precision ground Guideways induction hardened and precision ground Automatic lubrication system in headstock and feed box


Free SINO DRO installed Free Taper turning attachment, installed 8” 3-jsw chuck with set reversible jaws 10” 4-jaw chuck with set reversible jaws 12” Face plate 5-1/2” large steady rest with roller jaws Oil pump on Apron for all guideways and leadscrews 2” follow rest Removable gap 4-way tools post Foot brake Coolant system Halogen Work light Full length splash guard (2) dead centers and (1) reducing sleeve MT6/MT4 Thread chasing dial Tool box and leveling pads OPTIONAL ITEMS - CALL FOR PRICE: PART#DPD610 10” Drive Plate PART#MCS-GML-1440HD Micro Carriage Stop PART#NW840 NEWALL DRO, DP-700, free install PART#5C 5-C Hand lever type collet closer, free install PART#900-0014 33 pc 5C collet set, from 1/16 to 1-1/16” by 32ndth PART#900-0051-300 ALORIS type QC tool post set, 6 pcs PART#900-0050-04 Live Center PART#2003-0004 5pc Indexable carbide turning set PART#2003-0014 3/8” carbide insert PART#Lathe package #1 includes: 5pc indexable carbide turning set# 2003-0004, 1/2 drill chuck # 700-0102, Chuck arbor # 700-0153 and 29pc Titanium drill bit set #5000-0001T


ManufacturerGMC Machine Tools
Stock NumberGML-1440HD
Max. swing over bed14-7/8"
Max. length of workpiece40"
Max. swing over cross slide10-1/16"
Max. Swing in gap23-1/4"
Width of Bed10-1/4”
Effective length in gap to spindle8-1/2"
Effective length in gap to chuck jaws3-1/2"
Spindle bore2-1/16” , D1-6
Taper of spindle centerM.T.# 6 (with MT6/MT4 sleeve)
Spindle speeds45-1,800 rpm / 16 steps
Longitudinal feeds0.0018-0.07 IPR, 42 kinds
Cross feeds0.0009-0.03 IPR, 42 kinds
Inch threads70-2 TPI, 45 kinds
Metric threads0.2-14 mm, 39 kinds
Module threads0.3-3.6 mm, 18 kinds
Diametral Pitch threads8-40 DP , 21 kinds
Max. travel of top slide4-1/4”
Max. travel of cross slide8-1/2"
Spindle length without chuck20-1/2"
Leadscrew dia. x TPI1-1/4" diameter x 4 TPI
Diameter of tailstock quill2-1/16"
Max. travel of tailstock quill5”
Headstock size16" x 17"
Taper of tailstock quill centerM.T. # 4
Main motor6 HP, 220V only, 3 phase
Coolant pump motor1/8 HP, 220V, 3 phase
Net weight, approx.4,350 lbs
Overall dimensions, LxWxH79” x 38” x 53”
