BIRMINGHAM Precision Gap Bed Lathe YCL-2280 22" x 80"

BIRMINGHAM Precision Gap Bed Lathe YCL-2280 22" x 80"

$18,150

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer BIRMINGHAM Precision Gap Bed Lathe YCL-2280 22" x 80" ITEM: Precision Gap Bed Lathe MANUFACTURER: BIRMINGHAM MODEL: YCL-2280 10 HP Main Motor One-piece cast iron base D1-8 Spindle with 3-1/8" bore No change gears required 12 Speeds from 45-1,600 RPM 60 Kinds of inch threads from 112-2 TPI 47 kinds of metric threads from 0.2 - 14mm Main spindle hardened & precision ground Bed made of fine grain high tensile cast iron Bedways induction hardened & precision ground All gears & shafts hardened & precision ground Main spindle supported at 3-point by precision bearings STANDARD EQUIPMENT: 3 JAW CHUCK 4 JAW CHUCK FACE PLATE STEADY REST W/ ROLLER JAWS FOLLOW REST GAP 4 WAY TOOL POST THREADING CHASING DIAL ( 2 ) DEAD CENTERS REDUCING SLEEVE FULL LENGTH SPLASH GUARD ONE PIECE CAST IRON BASE FOOT BRAKE HALOGEN WORK LIGHT COOLANT SYSTEM LEVELING PADS 4 POSITION AUTO KICK-OUT LONGITUDINAL CARRIAGE STOP TOOL BOX TAPER TURN ATTACHMENT 10" LARGE STEADY REST W/ ROLLER JAWS 5C HAND LEVER TYPE COLLET CLOSER "JFK" USA 5C COLLET CHUCK (FRONT OPERATE) D1-6 MOUNT DIGITAL READOUT: " NEWALL DP-700 " OR " ACU-RITE " OR " UNIQ IMPORT"

Specifications

ManufacturerBirmingham
ModelYCL-2280
ConditionNew
Stock NumberYCL-2280
Distance between centers80"
Max. effective cutting length75-1/2"
Max. swing over cross slide13-3/4"
Max. swing in gap31"
Effective length in gap6"
Width of bed13-3/4"
Diameter of spindle thru bore3-1/8"
Taper of spindle centerMT #7 / MT # 5
Spindle speeds, 12 steps25, 35, 55, 80, 120, 170, 235, 350, 525, 700, 1100, 1600 RPM
Cross feeds35 kinds, 0.00048" - 0.01354"/rev.
Metric threads47 kinds, 0.2 - 14mm
Inch threads60 kinds, 112 - 2 TPI
Module threads39 kinds, 0.1 - 7mm
Diametral pitch threads50 kinds, 4 - 112 DP
Max. travel of top slide5-1/8"
4-way tool post size1" x 1"
Longitudinal leadscrew dia./pitchDia 1-5/8" / 4 TPI
Taper of tailstock quill centerMT #5
Max. travel of tailstock quill7"
Power of coolant pump1/8 HP, 60Hz, 3 phase Prewired 230V
Net weight, approx (lbs.)6,000
Gross weight, approx. (lbs.)6,600
