BIRMINGHAM Precision Gap Bed Lathe YCL-2260 22" x 60"
BIRMINGHAM Precision Gap Bed Lathe YCL-2260 22" x 60"
Contact us for price
Description
Please note: many products ship straight from manufacturer BIRMINGHAM 22" x 60" Precision Gap Bed Lathe YCL-2260 22" x 60" 10 HP Main Motor One-piece cast iron base D1-8 Spindle with 3-1/8" bore No change gears required 12 Speeds from 45-1,600 RPM 60 Kinds of inch threads from 112-2 TPI 47 kinds of metric threads from 0.2 - 14mm Main spindle hardened & precision ground Bed made of fine grain high tensile cast iron Bedways induction hardened & precision ground All gears & shafts hardened & precision ground Main spindle supported at 3-point by precision bearings
STANDARD EQUIPMENT: 3 JAW CHUCK 4 JAW CHUCK FACE PLATE STEADY REST W/ ROLLER JAWS FOLLOW REST GAP 4 WAY TOOL POST THREADING CHASING DIAL ( 2 ) DEAD CENTERS REDUCING SLEEVE FULL LENGTH SPLASH GUARD ONE PIECE CAST IRON BASE FOOT BRAKE HALOGEN WORK LIGHT COOLANT SYSTEM LEVELING PADS 4 POSITION AUTO KICK-OUT LONGITUDINAL CARRIAGE STOP TOOL BOX TAPER TURN ATTACHMENT
OPTIONAL ITEMS: CALL FOR PRICE 10" LARGE STEADY REST W/ ROLLER JAWS 5C HAND LEVER TYPE COLLET CLOSER "JFK" USA 5C COLLET CHUCK (FRONT OPERATE) D1-6 MOUNT DIGITAL READOUT: " NEWALL DP-700 " OR " ACU-RITE " OR " UNIQ IMPORT"
Specifications
| Manufacturer | Birmingham |
| Model | YCL-2260 |
| Condition | New |
| Stock Number | YCL-2260 |
| Distance between centers | 60" |
| Max. effective cutting length | 56" |
| Max. swing over cross slide | 13-3/4" |
| Max. swing in gap | 31" |
| Effective length in gap | 6" |
| Width of bed | 13-3/4" |
| Diameter of spindle thru bore | 3-1/8" |
| Taper of spindle center | MT #7 / MT # 5 |
| Spindle speeds, 12 steps | 25, 35, 55, 80, 120, 170, 235, 350, 525, 700, 1100, 1600 RPM |
| Cross feeds | 35 kinds, 0.00048" - 0.01354"/rev. |
| Metric threads | 47 kinds, 0.2 - 14mm |
| Inch threads | 60 kinds, 112 - 2 TPI |
| Module threads | 39 kinds, 0.1 - 7mm |
| Diametral pitch threads | 50 kinds, 4 - 112 DP |
| Max. travel of top slide | 5-1/8" |
| 4-way tool post size | 1" x 1" |
| Longitudinal leadscrew dia./pitch | Dia 1-5/8" / 4 TPI |
| Taper of tailstock quill center | MT #5 |
| Max. travel of tailstock quill | 7" |
| Power of coolant pump | 1/8 HP, 230/460V / 60Hz, 3 phase Prewired 230V |
| Net weight, approx (lbs.) | 5,200 |
| Gross weight, approx. (lbs.) | 6,000 |
