U.S. INDUSTRIAL Hydraulic Ironworker USHI-66T-DO

U.S. INDUSTRIAL Hydraulic Ironworker USHI-66T-DO


orCall 386-304-3720


Please note: many products ship straight from manufacturer U.S. INDUSTRIAL 66 Ton Hydraulic Ironworker USHI-66T-DO Dual Hydraulic cylinders for two-man operation with two movable foot pedals Five workstations: punch, plate shear, angle shear, rod shear notcher plus brake attachment Punch station has large two-piece gauging table with fence Punch station has quick acting swing-away stripper with 3 inserts Punch station has removable sections for punch leg of channel or I-beam Quick change coupling nut and sleeve for punch Electric backgauge, 3' long Electrically interlocked safety guard for notching station Magnetic base workstation light Three sets of round punch and die Spare parts and tools


ManufacturerUS Industrial
Stock NumberUSHI-66T-DO
Punch Tonnage66
Punching Thickness5/8"
Punching Diameter1-1/4"
Throat Depth12"
Stroke Length0" - 3 1/8"
Flat Bar Shear Max. Thickness12' x 5/8"
Flat Bar Max. Length16" x 5/16"
Flat Bar Blade Length16"
Angle Shear Capacity 90°5" x 5" x 3/8"
Angle Shear Capacity 45°2" x 2" x 1/4"
Bar Shear Round1-3/4"
Bar Shear Square1-5/8"
Notcher Thickness3/8"
Notcher Width2-1/4"
Notcher Depth4"
Motor7.5 HP
Oil Capacity20 gals.
Machine Dimensions64" x 28" x 69"
Machine weight approx.3,527 lbs
