TENNSMITH Universal Hand Brake EBT6016
TENNSMITH Universal Hand Brake EBT6016
$8,640
Description
Please note: many products ship straight from manufacturer TENNSMITH Universal Hand Brake EBT6016 ITEM: 60" x 16 ga. Universal Hand Brake MANUFACTURER: TENNSMITH MODEL: EBT6016 MADE IN USA TENNSMITH'S EBT Series is a versatile machine that allows for the removal and repositioning of both the upper and lower segments for forming complex parts. In addition, the EBT incorporates gas spring cylinders in lieu of traditional counterweights to assist in the bending process and the raising and lowering of the upper beam. The brake also features goat's foot style upper beam tooling. Common applications include: Architectural and ornamental metal forming Signage Aircraft panel fabrication
Specifications
| Manufacturer | Tennsmith |
| Model | EBT6016 |
| Condition | New |
| Stock Number | 85340 |
| Capacity - Mild Steel | 16 gauge |
| Bending Length | 60-1/4" |
| Maximum Lift of Beam | 4" |
| Bending Beam Adjustment | 1" |
| Minimum Reverse Bend | 5/8" |
| Segmented tooling width | 20, 12, 8, 6, 4, 1.5, 1 |
| Maximum Box Depth | 4-1/8" |
| Maximum Traverse Bend (through tooling centers) | 2-1/4" |
| Overall Dimensions | 72" x 45-1/2" x 31-1/2" |
| Shipping Weight: | 1,150 lbs. |
