SHARP Automatic Surface Grinder SG-618-2A

SHARP Automatic Surface Grinder SG-618-2A

Contact us for price

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer SHARP 6" x 18" Automatic Surface Grinder SG-618-2A Auto infeed (Y), auto longitudinal feed (X) Manual downfeed (Z), ball screw on Y axis Double V ways for cross travel, one V one flat way for longitudinal travel. Slide ways are hand scraped and coated with TURCITE B. Automatic cross feed. Accurate slot grinding using saddle locking system and ball screw cross feed. Advanced hydraulic system with independent oil tank for vibration free table. Automatic lubrication system. Hydraulic table stroke setting. STANDARD EQUIPMENT: Grinding Wheel (8” x 1.25” x 0.63”) Wheel adapter/flange Auto lube system Coolant system (12 gal.) Work light Balance arbor Diamond dresser Tool kit ITEM: 6" x 18" Automatic Surface Grinder MANUFACTURER: SHARP MODEL: SG-618-2A

Specifications

ManufacturerSharp
ModelSG-618-2A
ConditionNew
Stock NumberSG-618-2A
Maximum grinding width5.9"
Max distance: table to spindle center15.7"
Maximum longitudinal travel21.6"
Maximum cross travel7"
Hand feed per revolution (longitudinal)2.7 ft./rev
Continuous transverse feed47.2 in/min
Hand feed0.2 in/rev
Graduation of hand wheel0.0001”
Spindle speed3,600 RPM
Grinding wheel outside diameter8"
Grinding wheel bore1.25"
Grinding wheel width0.63"
Floor space (W x H x L)83" x 51" x 80"
Net weight (approximately)2,200 lbs.
