BURR KING 3-Wheel Belt Grinder MODEL 482

BURR KING 3-Wheel Belt Grinder MODEL 482

$2,158 : For other configurations - Please Call for Price

orCall 386-304-3720

Description

Please note: many products ship straight from manufacturer BURR KING 2" x 48" 3-Wheel Belt Grinder MODEL 482

  • MADE IN USA
  • Burr King's family of three wheel grinders provides maximum versatility. Contact wheel, platen, work rest support, and loose belt grinding are precision controlled with positive belt tracking, quick belt change, and linear belt tension.
  • Constructed of rugged cast aluminum and precision machined components, every Burr King grinder delivers unexcelled grinding performance and reliability.
  • Available in easily adjusted variable speed and aggressive single speed.
  • Model 482 can be pedestal or bench mounted and uses a standard 48" belt up to 2" wide.
  • Contact wheel, platen and workrest support grinding
  • Slack belt grinding
  • Adjustable belt tension
  • Positive belt tracking/patented design
  • Quick belt change
  • Large throat clearance for enhanced work point access
  • Precision machined cast aluminum frame
  • Accepts internal grinding attachments
  • Accepts nylon, buffing, wire, fiber wheels
  • Must remove wheel guard to fit 6" diameter wheels
  • Compact footprint friendly to "cell" manufacturing
  • OSHA compliant, enclosed guarding.
  • Pedestal is optional, not included.
  • *Includes magnetic starter (NEMA 12) and controls without power cord. (for 3 phase)
  • CAUTION: Use proper eye, face, hand and body protection when using this or any other grinder.


Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 1 YEAR

Specifications

ManufacturerBurr King
Model482
ConditionNew
Stock Number40100
Voltage/Phase120/1
Belt Size2" x 48"
SpeedFixed Speed 6,000 SFPM
Hz60
HP1
Shipping Weight85 lbs.
