ERCOLINA Angle Roll-Section Bender CE35

No longer available

ERCOLINA Angle Roll-Section Bender CE35



Please note: many products ship straight from manufacturer

ERCOLINA Angle Roll-Section Bender CE35

ITEM: 1-1/2" Angle Roll-Section Bender



Ercolina’s CE35 angle roll offers the convenience of operating in the vertical or horizontal position. Bending speeds 20% faster than competitive machines Universal tooling set included with each machine – 6-5/8" OD Forged roll shafts precision ground and fitted for maximum performance and minimal deflection Heavy duty structure and rigid components for high section modulus ratings Heavy duty gearbox drives lower roll shafts Control Tower with foot pedal operation of roll movement Reinforced engineered mainframe design proven to outperform competitive models Threaded roll shafts with micrometric flange adjustment helps eliminate spacer usage Inline direct drive roll shaft system All Ercolina angle roll-section bending machines include universal tooling sets.


Stock NumberCE35
Pipe (Max.)1 1/2" Sch. 40
Angle (Max.)1-1/2" x 1-1/2" x 1/4"
Tube (Max.)2" – .156 wall
Roll Shaft Diameter40mm
Center Roll PositioningManual
Shaft Speed6 or 12 RPM
Universal Tooling (Included)6-5/8" O.D.
ProgrammingNot Available
Distance between Shafts11-3/8"
Operating Voltage220V, 1ph
Length, Width, Height27-1/2" x 25-1/2" x 59"
Weight480 lbs.
