ROPER WHITNEY 4' x 22 ga. Connecticut Bench Brake U-422

PART# 155100422

  • Connecticut bench mounted hand brakes are rugged, dependable USA-made tools. The model U422 is a heavy duty bench brake suitable for box and pan or straight bending up to 22-gauge mild steel. The brake features a removable apron angle and apron insert permitting 1/4-inch reverse bends in lighter materials. The front to rear adjustment of the U422 allows for a wide range of radius bending. Standard equipment includes: an apron stop rod for repeat bends, extension handles and counterweight to help reduce fatigue when using the brake. The lighter weight makes this model better suited for transporting to remote job sites. Connecticut bench-mounted hand brakes provide an economical means of performing a wide range of sheet metal bending and forming operations. These brakes are of all- steel welded construction, readily adjustable and backed by an industry leading 3-Year Factory Warranty.


  • 239005012 - Bolt-together Floor Stand: $270.00

Specifications are subject to change without notice.

NOTE: Data is provided by the manufacturer.

WARRANTY: 3 YEAR – Limited

Note: Consumable tooling is not covered under the 3 year manufacturer’s warranty.


ManufacturerRoper Whitney
Stock Number155100422
Bending Length48"
Capacity on mild steel, 1" flange With bending bar and angle in place22 ga.
Minimum reverse bend5/16"
Maximum lift of beam7/8"
Finger widths2", 3", 4"
Maximum Depth of Box3"
Front to Rear Adjustment of Beam1/4"
Shipping Weight280 lbs.
Dimensions61" x 20" x 28"
